Bluetooth and Wi-Fi (Wireless LAN)
This product is controlled by the United States Export Administration Regulations (EAR). The permission of the United States government is not required for export to countries other than the following, which as of this writing are subject to embargo or special controls: Cuba, Iran, North Korea, Sudan, and Syria (list subject to change).
The use of wireless devices may be prohibited in some countries or regions. Contact a Nikon-authorized service representative before using the wireless features of this product outside the country of purchase.
The Bluetooth transmitter in this device operates in the 2.4 GHz band.
This device complies with part 15 of FCC Rules and Innovation, Science and Economic Development Canada’s licence-exempt RSSs. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
FCC WARNING
The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Nikon Corporation may void the user’s authority to operate the equipment.
Compliance with FCC requirement 15.407(c)
Data transmission is always initiated by software, which is the passed down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets are initiated by the MAC. These are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets is being transmitted. In other words, this device automatically discontinue transmission in case of either absence of information to transmit or operational failure.
Frequency Tolerance: ±20 ppm
FCC Radio Frequency Interference Statement
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
-
Reorient or relocate the receiving antenna.
-
Increase the separation between the equipment and receiver.
-
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
-
Consult the dealer or an experienced radio/TV technician for help.
Co-location
This transmitter must not be co-located or operated in conjunction with any other antenna or transmitter.
Nikon Inc., 1300 Walt Whitman Road, Melville, New York 11747-3064, U.S.A.
Tel.: 631-547-4200
FCC/ISED RF Exposure Statement
The available scientific evidence does not show that any health problems are associated with using low power wireless devices. There is no proof, however, that these low power wireless devices are absolutely safe. Low power Wireless devices emit low levels of radio frequency energy (RF) in the microwave range while being used. Whereas high levels of RF can produce health effects (by heating tissue), exposure of low-level RF that does not produce heating effects causes no known adverse health effects. Many studies of low-level RF exposures have not found any biological effects. Some studies have suggested that some biological effects might occur, but such findings have not been confirmed by additional research. This product has been tested and found to comply with FCC/ISED radiation exposure limits set forth for an uncontrolled environment and meets the FCC radio frequency (RF) Exposure Guidelines and RSS-102 of the ISED radio frequency (RF) Exposure rules. Please refer to the SAR test report that was uploaded to FCC website.
Compliance with RSS-247 Issue 2 §6.4
Data transmission is always initiated by software, which is the passed down through the MAC, through the digital and analog baseband, and finally to the RF chip. Several special packets are initiated by the MAC. These are the only ways the digital baseband portion will turn on the RF transmitter, which it then turns off at the end of the packet. Therefore, the transmitter will be on only while one of the aforementioned packets is being transmitted. In other words, this device automatically discontinue transmission in case of either absence of information to transmit or operational failure.
For indoor use only (5150-5350MHz).
Hereby, Nikon Corporation declares that the radio equipment types Z 7II and Z 6II
are in compliance with Directive 2014/53/EU.
The full texts of the EU declarations of conformity are available at the following internet addresses:
Z 7II:
https://imaging.nikon.com/support/pdf/DoC_N1932.pdf
Z 6II:
https://imaging.nikon.com/support/pdf/DoC_N1929.pdf
Wi-Fi
-
Operating frequency:
-
2412–2462 MHz (channel 11; Africa, Asia, Bolivia, and Oceania)
-
2412–2462 MHz (channel 11) and 5180–5825 MHz (U.S.A., Canada, Mexico)
-
2412–2462 MHz (channel 11) and 5180–5805 MHz (other countries in the Americas)
-
2412–2462 MHz (channel 11) and 5745–5805 MHz (Georgia)
-
2412–2462 MHz (channel 11) and 5180–5320 MHz (other European countries)
-
-
Maximum output power (EIRP):
-
2.4 GHz band: 5.2 dBm
-
5 GHz band: 5.3 dBm (Georgia)
-
5 GHz band: 8.3 dBm (other countries)
-
Bluetooth
-
Operating frequency:
-
Bluetooth: 2402–2480 MHz
-
Bluetooth Low Energy: 2402–2480 MHz
-
-
Maximum output power (EIRP):
-
Bluetooth: –0.3 dBm
-
Bluetooth Low Energy: –1.8 dBm
-
Hereby, Nikon Corporation declares that the radio equipment type Z 7II and Z 6II are in compliance with Radio Equipment Regulations 2017.
The full text of the UKCA declaration of conformity is available at the following internet address:
Z 7II:
https://imaging.nikon.com/support/pdf/UKCA_DoC_N1932.pdf
Z 6II:
https://imaging.nikon.com/support/pdf/UKCA_DoC_N1929.pdf
Wi-Fi
-
Operating frequency:
-
2412–2462 MHz (channel 11) and 5180–5320 MHz
-
-
Maximum output power (EIRP):
-
2.4 GHz band: 5.2 dBm
-
5 GHz band: 8.3 dBm
-
Bluetooth
-
Operating frequency:
-
Bluetooth: 2402–2480 MHz
-
Bluetooth Low Energy: 2402–2480 MHz
-
-
Maximum output power (EIRP):
-
Bluetooth: –0.3 dBm
-
Bluetooth Low Energy: –1.8 dBm
-
This product complies with the UK PSTI Act 2022 and the statement of compliance and security update period is available at the following internet address:
https://www.nikonimgsupport.com/eu/BV_article?lang=en_GB&articleNo=000066765
This device complies with radio-frequency regulations. The content of certification
labels not affixed to the device is given below.
Although one of the benefits of this product is that it allows others to freely connect for the wireless exchange of data anywhere within its range, the following may occur if security is not enabled:
-
Data theft: Malicious third-parties may intercept wireless transmissions to steal user IDs, passwords, and other personal information.
-
Unauthorized access: Unauthorized users may gain access to the network and alter data or perform other malicious actions. Note that due to the design of wireless networks, specialized attacks may allow unauthorized access even when security is enabled.
-
Unsecured networks: Connecting to open networks may result in unauthorized access. Use secure networks only.
The standards with which the camera complies can be viewed using the [] option in the setup menu.
